Lexmark 4036-307 - Paper Feed Motor Removal

Repair information 4-17
4036-307, -308
Paper feed motor removal
1. Remove the ADF lower cover. See “ADF lower cover removal” on page 4-4.
2. Remove the three screws (A) securing the paper feed motor.
3. Disconnect the cable (B).
4. Remove the paper feed motor.
AB
