Lexmark 4036-307 - Keypad Removal

Repair information 4-25
4036-307, -308
5. Remove the screw (B) to disconnect the cable from the touch screen.
6. Disconnect the cable (C) from the keypad board.
Keypad removal
1. Remove the control panel keypad board. See “Control panel keypad board removal” on page 4-23.
2. Lift the keypad out.
BC
