Diagnostic information 2-31
4036-307, -308
Other LCD touch-screen buttons
Button Button name Function or description
Custom Allows for creating a custom button based on the user’s needs.
Cancel Cancel an action or a selection, or cancel out of a screen and return to the
previous screen.
Select Select a menu. The next screen appears showing menu items.
Select a menu item. The next screen appears showing values.
Done Specify that a job is finished. For example, when scanning an original
document, one can indicate that the last page is scanned, and then the print
job begins.
Back Return to the previous screen without saving any settings from the screen.
Note: The Back button appears on each menu screen except for the home
screen.
Home Return to the home screen.
Note: The Home button appears on every screen except the home screen.
For more information, see the Home screen on page 8.
Reset active bin Define the active bin as the start bin (the first bin to receive printed output) in
a set of linked bins.
Note: This button only appears when the MFP is in a stopped state.
Grayed out button When this button appears, it looks faded with a faded word on it. It means
the button is not active or is unavailable on this screen. It was probably
active on the previous screen, but the selections made on the previous
screen caused it to be unavailable on the current screen.
Gray button Touch this button to select the action appearing on the button.
Cancel
Done
Back
Reset
active bin
