1-2 Service Manual
4036-307, -308
Scanner specifications
The scanner is designed to meet the following product specifications:
Scanner
Scanner Type Flatbed Scanner with ADF built in
Optical Resolution 600 x 600 dpi (mono)
600 x 300 dpi (color)
Scan Speed 17 ppm at 600 dpi color for single page scanning
40 spm at 600 dpi line-art, duplex for ADF
Scan Method Color Charge-Coupled Device (CCD)
Light Source Cold Cathode Fluorescent Lamp (CCFL)
Scan Area Max. 8.5 x 14.0 inch (legal size) for ADF
Display 640 x 480 color VGA touch screen
Image Types 42-bit color (internal)
14-bit gray (internal)
1-bit line-art, Dither, Error Diffusion
Scan Accuracy Flatbed ADF
• Leading Edge <-1 ~ +2 mm <2.5 ~ +2.5 mm
• Side Edge <-1 ~ +2 mm <2.5 ~ +2.5 mm
• Skew <1 mm <2 mm
• Magnification Rate Tolerance
(width and length)
-1.5% ~ +1.5% -1.5% ~ +1.5%
Physical Dimension
• Width 525 mm
• Depth 515 mm
• Height 370 mm
• Weight 14.51 kg
Environment Temperature Humidity
• Operating 15.6°C to 32.2°C (60°F to 90°F) 8% to 80% RH (relative
humidity)
• Storage -40°C to 65°C (-40°F to 149°F) 8% to 90% RH (Relative
Humidity)
Acoustic noise Operating: 58 dB or less
Electrostatic discharge EC 1000-4-2 ESD Standard
Safety regulation UL, CSA, TUV/GS, SEMKO
EMC regulation FCC Part 15 Subchapter J Class A
CE Marking, C-Tick
ADF
