Lexmark 4036-307 - Control Panel Keypad Board Removal

Repair information 4-23
4036-307, -308
Control panel keypad board removal
1. Remove the control panel assembly. See “Control panel assembly removal” on page 4-24.
2. Disconnect the three cables (A) from the keypad board.
3. Remove the six screws (B) that secure the board.
4. Remove the board from the control panel assembly.
B
A
