General information 1-3
4036-307, -308
Tools required for service
Flat-blade screwdriver
#1 Phillips screwdriver, magnetic
#2 Phillips screwdriver, magnetic
#2 Phillips screwdriver, magnetic short-blade
Needlenose pliers
Diagonal side cutters
Spring hook
Feeler gauges
Analog or digital multimeter
Acronyms
General specifications
• Optical Resolution 600 x 600 dpi (mono)
600 x 300 dpi (color)
• Document Capacity 50 sheets
Document
• Document size Max. 8.5 x 14 inch (W x L) Min. 4.5 x 5.5 inch (W x L)
• Thickness 0.05~0.15 mm
ADF Automatic Document Feeder
CCD Charge-Couple Device
CCFL Cold Cathode Fluorescent Lamp
CDB Command Descriptor Blocks
CRU Customer Replaceable Unit
ESD Electrostatic Discharge
FRU Field Replaceable Unit
HV High Voltage
LCM Liquid Crystal Module
LED Light-Emitting Diode
LV Low Voltage
MFD Multi Function Device
PCBA Printed Circuit Board Assembly
PPM Page per minute
SPM Sides per minute
V ac Volts alternating current
V dc Volts direct current
