Repair information 4-27
4036-307, -308
Control panel display assembly removal
1. Remove the control panel assembly. See “Control panel assembly removal” on page 4-24.
2. Disconnect the four cables (A).
3. Remove the six screws (B).
4. Turn the control panel assembly over, carefully. The bezel and display are loose.
5. Lift the bezel (C).
6. Remove the control panel display assembly.
B
B
A A
C
