Parts catalog 7-3
4036-307, -308
Assembly 1: ADF assembly
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
1—1 40X2530 1 1 Scanner, entire
2 40X2180 1 1 Document cover assembly
3 40X4755 1 1 Pick pad
4 40X2532 1 1 Document input tray
5 40X2542 1 1 Paper length sensor
6 40X2550 1 1 ADF/CCD motor cable (10-pin)
7 40X2551 1 1 ADF/CCD data cable (26-pin)
8 40X2547 1 1 ADF paper feed motor
9 40X2548 1 1 ADF interface board
10 40X2533 1 1 Paper stop
11 40X2549 1 1 ADF sensor cable (6-pin)
12 40X2543 1 1 ADF FF to motor/distribution cable
13 40X2546 1 1 Paper feed motor cable (4-pin)
14 40X2552 1 1 ADF motor/distribution board
15 40X2534 1 1 Scanner cushion
16 40X2541 1 1 Paper present/feed 1 sensors
17 40X2586 1 1 Paper present/feed 1 ground cable
18 40X2192 1 1 ADF lamp
19 40X2184 1 1 Paper feed assembly with paper feed 2 sensor
20 40X2598 1 1 ADF upper cover sensor
21 40X2537 1 1 ADF lower cover assembly, including
• ADF lower cover (1)
• Mylar (1)
22 40X2183 1 1 ADF optical unit assembly
23 40X2536 1 1 ADF outer cover
24 40X2535 1 1 ADF upper cover
25 40X2540 1 1 Pick roller assembly
