Parts catalog 7-7
4036-307, -308
Assembly 3: Lower scanner
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
3—1 40X2559 1 1 Flatbed cover with glass
2 40X2564 1 1 Document cover sensor board
3 40X2562 1 1 Carriage transport belt, includes
• Carriage transport belt
• Clip
4 40X2193 1 1 Flatbed CCD assembly, includes
• Flatbed CCD assembly
• Flatbed CCD lamp assembly
• Flatbed lamp CCD inverter board
5 40X2561 1 1 Flatbed CCD lamp assembly
6 40X2563 1 1 Flatbed lamp CCD inverter board
