Parts catalog 7-9
4036-307, -308
Assembly 4: Electronic boards
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
4—1 40X2580 2 1 Control cooling fan (1 cooling, 2 clips)
2 40X2567 1 1 Modem board (model 308 only)
3 40X2568 1 1 Power supply board
4 40X2572 1 1 Display cable
5 40X2195 1 1 Hard disk drive assembly
6 40X2573 1 1 Hard drive data cable (80-pin)
7 40X2581 1 1 AC jumper power cord
8 40X2565 1 1 A1 board with modem (model 308 only)
8 40X2179 1 1 A1 board without modem (model 307 only)
9 40X2574 1 1 Modem to scanner control cable (30-pin) (model 308 only)
10 40X2587 1 1 Document cover sensor cable
11 40X2578 1 1 A1 to scan control cable (12-pin)
12 40X2194 1 1 Scanner control board
13 40X2577 1 1 Hard drive PS cable (4-pin)
14 40X2571 1 1 Flatbed CCD cable (36-pin)
15 40X2575 1 1 Power distribution cable (2+3-pin)
16 40X2579 1 Motor cable
17 40X2570 1 1 Flatbed motor cable (16-pin)
18 40X2576 1 1 AC power cable (3+3-pin)
19 40X2588 1 1 Control panel ground cable
NS 40X2660 2 1 Modem display toroid
NS 40X2661 1 1 AC power cord toroid
