Maintenance
12-25
Remove the 4 nuts
from the support legs
2. Bend the supports out slightly to remove the bottom plate assembly.
3. Use a knife or razor blade to remove the old gasket. Clean the rim of the
chamber with alcohol if necessary to remove any adhesive residue.
4. Remove the adhesive backing from the new gasket and install around the rim
of the chamber. Trim the gasket as needed so that the ends are touching.
5. Apply a small amount of Loctite to glue the ends together (below).
To Next Page
