Getting Started

The system comes with the following components:

POWER CABLE

QUICKSTART GUIDES

DOCUMENTATION CD

USB MOUSE

ETHERNET CABLE

REMOTE CONTROL

(may not be exactly as

shown)

NVR (NETWORK VIDEO RECORDER)

HDMI CABLE

HARD DRIVE SIZE, NUMBER OF CHANNELS, AND CAMERA CONFIGURATION MAY VARY

BY MODEL. PLEASE REFER TO YOUR PACKAGE FOR SPECIFIC DETAILS.

CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE SYSTEM,

INCLUDING ALL COMPONENTS SHOWN ABOVE.
