8
Basic Setup
2 Adjust the camera stand to ensure that the camera has a satisfactory view of the area you
would like to monitor. Stand configuration depends on the mounting surface you have chosen
(see below for suggested stand configurations).
Table Mount
Wall Mount
Ceiling Mount
Camera model not be exactly as shown.
3 Connect a Cat5e or better Ethernet cable from the camera to the NVR. The NVR features
integrated PoE (Power over Ethernet) ports that provide both power and data transmission to
PoE-compatible cameras over the Ethernet cables.
NOTE: The
cameras may take up to 1 minute to power on and show an image on the monitor
aft
er being connected to the NVR.
