Troubleshooting
ProtoMat S64/S104
148/160
LPKF Laser & Electronics AG | V. 1.0
Description
Possible cause
Remedial measures
Error message: Input
pressure too low
The system input
pressure is too low.
Set the system input pressure at least to 6
bar.
Tool shank not
recognized.
The tool is not inserted
correctly.
Insert the tool correctly.
Soiled tool shank.
 Clean the tool shank.
 Replace the tool shank.
No LPKF tool.
 Use LPKF tools.
 Adjust the camera parameters.
Wrong camera
parameters.
Adjust the camera parameters.
Wrong ring position.
Correct the ring position.
Fiducial not found
Unsuitable parameters
Adjust the camera parameters.
Adverse material surface
(strong reflection).
Process the surface with abrasive fabric or
the like.
Adverse material surface
(oxidized).
Process the surface with abrasive fabric or
the like.
Milling width not found
Unsuitable camera
parameters.
Adjust the camera parameters.
Adverse material surface
(strong reflection).
Process the surface with abrasive fabric or
the like.
Error message:
Material is too thick
Wrong material selected.
Observe the maximum allowed material
thickness = 8 mm.
Copper thickness -
9999
Measurement has been
performed at an
inappropriate position.
Change the position and measure again
(surrounded by 25 mm copper).
Camera connection
failed.
Connection cable too
long.
Use the cable provided in the scope of
delivery.
Plug not inserted
correctly.
Reinsert the plug.
The measurement
unit for the copper
layer thickness does
not extend.
Measurement unit is
jammed
Check the installation of the dispenser unit.
Wrong setting of the
pressure reducer for
measuring the copper
thickness.
Contact the LPKF Service.
While putting down
the tools, they are not
completely pushed
into the tool holder.
Chips in the tool holder
or at the tool.
Clean the tool holder and the tool.
Chip ball at the drilling
tool.
Use the cleaning device (see page 104.
Drilling tool heavily
soiled
No cleaning device
used.
Use the cleaning device (see page 104.
Unsuitable drilling
parameters e.g. for
custom tools.
Correct the drilling parameters.
