Operating the system
ProtoMat S64/S104
90/160
LPKF Laser & Electronics AG | V. 1.0
 The computation results and the tools required for the project are displayed.
Fig. 77: Computation results
5. Check whether all required tools are available.
The warning message indicates that source data are missing for some
computation functions. This is not an error but a notice for the user.
Advanced information
The computation results of CircuitPro PM recommend which tools should be used for
processing the generated toolpaths. If one of the listed tools is not available, you can
assign another tool to the generated toolpath afterwards in the pane Toolpath.
Please note that using tools with different diameters can cause results that differ from
the computed data.
You can also deactivate tools that are not available in the Technology dialog using
Show details so that these are not used for toolpath generation.
6. Click on [Close].
