UM-1151140EN, Rev. C, May 2016
Laser
Safety
and
Regulatory
Symbol Description
Electrical and Fuses Requirements
Auxiliary Monitor Connection Port
Service (Ethernet) Connection Port
USB Connection Port
Footswitch Connection Port
Eye Safety Filter Connection Port
LIO Connection Port
Pattern Link Connection Port
Remote Interlock Connection Port
Water Ingress Protection Level – Standard &
Smart Footswitches
Water Ingress Protection Level – PowerEase
Footswitch
