MAINTENANCE, LUBRICATION AND SERVICE
ELECTRICAL SYSTEM
No.
Rated
curren
t
Function
F51 10 A M-DRIVE GEAR SHIFT
ECU
F52
10 A INSTRUMENT CLUSTER
(IC)
F53
5 A BODY BUILDER MODULE/
INSTRUMENT CLUSTER
EMS POWER
F54
10 A TRANS / PARKER PTO
F55 10 A OPEN
F56 10 A BENDIX FUSION LANE
DEPARTURE WARNING
SYSTEM
F57
15 A SNOW PLOW LAMPS LH
F58 15 A SNOW PLOW LAMPS RH
F59 10 A SEAT SAFETY RESTRAINT
SYSTEM
F60
30 A HVAC FAN
F61 5 A LVD SENS/VENDOR
TELEMATICS
F62
10 A CB POWER
F63 15 A CUSTOMER USE /
AUXILIARY SWITCH 3
F64
15 A OPEN
F65 10 A OPEN
F66 30 A M-DRIVE
F67 10 A OPEN
No. Rated
curren
t
Function
F68 10 A RADIO
F69 10 A VECHICLE ECU
(ELECTRIC CONTROL
UNIT)
F70
10 A OPEN
F71 15 A CENTER PIN HOT
(PRIMARY SAEJ560)
F72
5 A OPEN
F73 5 A ACC/ SIDE SENSOR/ECS
F74 10 A OPEN
F75 25 A WIPER
F76 30 A CENTER PIN HOT, ISO
3731
F77
10 A BENDIX FUSION
F78 25 A LIGHT CONTROL
MODULE 2
F79
25 A LIGHT CONTROL
MODULE 4
F80
10 A DIAGNOSTIC CONN
F81 20 A LIGHT CONTROL
MODULE 1
F82
20 A LIGHT CONTROL
MODULE 6
F83
20 A LIGHT CONTROL
MODULE 5
F84
10 A POWER DOOR LOCKS
No. Rated
curren
t
Function
F85 5 A TELEMATIC GATEWAY
F86 15 A BEACON LAMP
F86 10 A ELECTRONIC
CONTROLLED
SUSPENSION
F87
15 A CUSTOMER USE
Relays
No. Function
R1 ACCESSORY POWER
R2 RADIO WAKE
R3 NEUTRAL POWER
R4 VENDOR START ENABLE
R5 CENTER PIN HOT
R6 ISO PIN HOT
R7 SNOW PLOW RH
R8 SNOW PLOW LH
R9 DOME/DOOR LAMPS
R10 CITY HORN
R11 START ENABLE
R12 HVAC BLOWER
R13 SNOW PLOW LCM INPUT
R14 LIFT AXLE/REVERSE SIGNAL
R15 ALLISON BODYBUILDER
261
