Ultra Electronics Card Systems
Rio Pro Maintenance Manual
Function is called upon receiving a LNG command.
The function takes a single numeric parameter, which is used to set the Boot Up Language for
Status and Error Messages.
The possible parameter values are as follows:
0 - ENGLISH
1 - PORTUGUESE
2 - FRENCH
3 - GERMAN
4 - SPANISH
5 – ITALIAN
Function is called upon receiving a RUN command.
The function takes a single parameter, and enables various tests to be performed
The possible parameter values are as follows:
CAM - Runs the Cam Motor while displaying the Cam Sensor State
FEED - Runs the Feed Motor Backwards
DYE - Runs the Dye Motor while displaying the Tacho Sensor State
MAIN - Runs the Main Stepper Motor
FLIPPER - Runs the Flipper Rotation Motor while displaying the Flipper Position Sensor State
FLIPROLL - Runs the Flipper Card Drive Motor
FAN - Runs the Print Head Cooling Fan
PANEL - Displays the current state of the Dye Film Sensor
POUT - Raises the P-OUT line for 5 seconds
CAL - Sets the LEDs in the Middle and Rear Card Sensors to Bright Mode for 5 seconds
LCD - Cycles the LCD backlight through its entire range of Colours
OFF - Turns Off all Motors
Function is called upon receiving a FLM command.
The function takes a Single Parameter, which may be either Y,M,C,K or O, and Aligns the Ribbon at
the Corresponding Panel.
Function is called upon receiving a FCL command.
The function, with no parameter, initiates the Dye LED Calibration Routine. If a parameter is
supplied, it must be in the form of a # sign followed by a Six Digit Hexadecimal Number, which is
then used to set the dye LED Colour directly.
