Magicard Rio Pro - Page 83

Ultra Electronics Card Systems
Rio Pro Maintenance Manual
- 83 -
Quick Command
Function
FLIP
Function is called upon receiving a FLIP command.
If Duplex Printing is Enabled, and there is a Card in the Print Engine, this function will Feed the
Card into the Flipper Mechanism, rotate it, and return it to the Printer.
FRN
Function is called upon receiving a FRN command.
The function enables/disables the Film Saving Feature (required for printing with Short Colour
Panels).
It takes a single parameter of either ON or OFF.
HEAD
Function is called upon receiving a HEAD command.
This function takes a Single Parameter, either UP or DOWN, and raises or lowers the Print Head
accordingly.
RAMP
Function is called upon receiving a RAMP command.
The function sets the Density Ramp adjustment according to the given numeric parameter
(between 0 and 100 where 50 is the Default Setting).
SET
Function is called upon receiving a SET command.
This function saves the current printer settings into the Protected Memory Area.
TST
Function is called upon receiving a TST command.
This function initiates an Internal Test Print.
STN
Function is called upon receiving a STN command.
This function causes the printer to re-initialise the Internal Holokote Images.
SNS
Function is called upon receiving a SNS command.
Operates a single “Soak Cycle” and checks all Sensors.
SHW
Function is called upon receiving a SHW command.
This function enables the Sensor Status to be reflected at the front panel LEDs.
It takes a single parameter, which specifies the sensor to be tested.
The possible values for the parameter are:
CAM - to test the cam sensor
TACHO - to test the tacho sensor
FLIP - to test the flip sensor
DYE - to test the dye film sensor
LID - to test the lid sensor
FRONT - to test the front Card sensor
MID - to test the mid Card sensor
REAR - to test the rear Card sensor
BUTTON1 - to test button 1 on the front panel
BUTTON2 - to test button 2 on the front panel
SMART - to test the encoder Card sensor
TEMP - to test the printhead temperature sensor
ON - to test all the optosensors at once
OFF - to terminate sensor test mode
Sending an invalid parameter is equivalent to SHWOFF.
