Reference Only
Manitowoc Published 05-09-17, Control # 011-29 3-63
16000 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
The number displayed in the crane status top bank
corresponds to the numbered communication errors listed
below:
0 — Crane status normal.
1 — Node-2 is not communicating.
2 — Node-3 is not communicating.
4 — Node-4 is not communicating.
8 — Node-5 is not communicating.
16 — Node-7 is not communicating.
32 — Bin node is not communicating.
64 — Wireless remote is not communicating.
128 — Engine node is not communicating.
NOTE: Bottom crane status bank is not used at this time.
Crane History
Top crane history bank displays errors since power was
cycled.
NOTE: Bottom crane history bank is not used at this time.
Load Link Status
The load link sensor icons indicate the selected load sensor
operating status. The selected link sensor is operating
normal if blue antenna icon is displayed. The following
numbers indicate the type of communication error:
4 — is a calibration fault.
8 — is RF (radio frequency) state. The selected link sensor is
not communicating.
64 — is a sign on error.
128 — indicates a RF (radio frequency) communication
error.
Drum load link and wireless remote battery status displays:
16 and 32 On — 75% and up battery charge
32 On, 16 Off — 50% to 75% battery charge
32 Off, 16 On — 25% to 50% battery charge
Both Off — 0% to 25% battery charge
Wireless Receiver Status
Wireless receiver status displays boom top and wireless
receiver communication. The following numbers indicate the
type of communication:
0 — Communication error.
1 — Boom top transmitter working.
2 — Rotating bed receiver working.
Boom Node Status
The boom node status displays boom top node and jib node
communication. Zero is displayed if there is a
communication error. Boom data box indicates what boom
nodes may be available on the bus:
0 — No communication.
1 — is boom top node.
2 — is luffing jib node.
4 — is fixed jib node.
128 — indicates a node is present that is not currently
identified.
