16000 OPERATOR MANUAL SET-UP AND INSTALLATION
4
Remove First Crawler
See Figure 4-14 for the following procedure.
Perform steps 1 through 4 at both crawlers.
1. Disconnect hydraulic hoses (Figure 4-12
) between
carbody and crawler:
• Connect hose (11, View A) to coupler (12a).
• Connect hose (12, View B) to coupler (11a).
• Attach dust cap to end of hose (13, View B) and to
coupler (13a). Secure hose to carbody for shipping.
2. Disconnect grease hose (14, Figure 4-12
, View C)
between carbody and crawler.
• Attach dust cap to end of hose and to coupler (14a).
• Secure hose to carbody for shipping.
3. Disconnect crawler drive (see Figure 4-14
):
a. Unpin drive shaft guard (9, View D) and slide guard
back.
b. Support drive shaft (4, View C) and remove flange
screws (8). Store screws in carbody flange holes
once drive shaft is disconnected.
c. Retract crawler drive shaft and place on storage
bracket (5, View B).
4. Attach chains (1, Figure 4-14
, View F) between crawler
pads (2) and crawler lugs (3) (four places). Chains
should be snug to prevent treads from sagging when
crawler is lifted.
5. Perform steps 3 - 7 on page 4-10
to deploy each
carbody jack.
6. Using controls on front of carbody, extend carbody jacks
until crawler treads are just clear of ground.
7. A 2-way level is provided near controls on front of
carbody to aid in jacking.
8. Attach hooks from chain sling (Figure 4-14
, View E) to
crawler as shown in Figure 4-11
.
9. Tilt operator’s cab up, as required, so crawler does not
hit cab.
10. Remove collars (3, Figure 4-13
, View D) and retract
crawler connecting pins (2) with crawler pins control (4
or 5, View G).
11. Slowly hoist and boom up or down as required to lift
crawler clear of carbody.
12. Position trailer under suspended crawler.
13. Lower crawler onto trailer.
14. Disconnect chains from crawler and remove trailer.
15. Engage crawler pins and install collars (3, Figure 4-13
,
View D).
Remove Second Crawler
1. Swing 180° so assembly block from mast is centered
over crawler.
2. Repeat steps 8 through 15 for other crawler.
Do not swing more than 10° either side of center when
handling second crawler.
Remove Assembly Block
Follow instructions on page 4-33.
CAUTION
Parts Damage!
Avoid hitting carbody jacks with crawlers.
WARNING
Moving Part Hazard!
To avoid serious crushing injury — warn all personnel to
stand clear of jacks.
Tipping Hazard!
Avoid tipping crane over — keep the crane level while
jacking.
DANGER
Tipping Hazard!
Do not allow assembly block to swing past inside edges of
carbody jacks while removing first crawler. Crane will tip.
WARNING
Tipping Hazard!
To prevent the crane from tipping — limit swing to 10°
either side of center when handling second crawler
(Figure 4-10
, View E).
