OPERATING CONTROLS AND PROCEDURES 16000 OPERATOR MANUAL
3-4
Published 05-09-17, Control # 011-29
SYMBOL IDENTIFICATION
The following symbols are used on the control consoles to identify the operating controls and their operation.
Alert, Safety
FIGURE 3-1
Air Circulation – Outside
Air Circulation – Cab
Cab Tilt
Cylinders, Live Mast –
Extend or Retract
Cylinders – Live Mast
Drum – Lower (Load, Boom,
Luffing Jib, or Mast) (depends
on drum use.)
Drum Free Fall
(with drum number)
Drum – Raise (Load, Boom,
Luffing Jib, or Mast) (depends
on drum use.)
Drum
3
3
OR
Data, Enter
Data, Save Entered
Cylinders, Jacking –
Extend or Retract
Cylinders, Jacking –
Location
Right Front
Left Rear
Right Rear
All
Left Front
Drum Number
(identifies drum is in use)
3
OR
