Manitowoc Published 05-09-17, Control # 011-29_v2 4-37
16000 OPERATOR MANUAL SET-UP AND INSTALLATION
4
Working Configuration with Boom (View B)
1. Disconnect terminating plug (2b, View A) from
receptacle (2a). Connect the sealing cap to the end of
the terminating plug and let the terminating plug hang
freely.
2. Connect electric cable (2c, View B) from the boom butt
to receptacle (2a).
3. Connect terminating plug (2e, View B) to electric cable
(2d).
4. If equipped with a luffing hoist, connect electric cable
(3b, View B) to receptacle (3a).
Working Configuration with MAX-ER
®
(View C)
1. Disconnect terminating plug (2b, View A) from
receptacle (2a). Connect the sealing cap to the end of
the terminating plug and let the terminating plug hang
freely.
2. Connect electric cable (2c, View B) from the boom butt
to receptacle (2a).
3. Connect terminating plug (2e, View B) to electric cable
(2d).
4. If equipped with a luffing hoist, connect electric cable
(3b, View B) to receptacle (3a).
5. Disconnect terminating plug (2e, View B) from electric
cable (2d). Connect the sealing cap to the end of the
terminating plug and let the terminating plug hang freely.
6. Connect electric cable (4b, View C) from the mast butt to
receptacle (4a).
7. Connect electric cable (2d, View C) to electric cable (4c).
CRANE DISASSEMBLY
Lower Boom
Perform steps 1 through 4 under Boom Removal topic to
lower the boom and jib (if equipped).
Disconnect Boom Butt from Boom
1. Disconnect boom wiring:
a. Disconnect electric cable (8, Figure 4-21
, View E)
(from boom) from electric cable (7) on crane.
b. Remove sealing cap and connect terminator plug
(6, View E) to electric cable (7). Also see Figure 4-5
,
View D.
c. Connect sealing cap to electric cable (8) and store
electric cable (8) on boom butt.
d. Disconnect electric cables (9, Figure 4-21
, View D)
and (10 optional) from node on front of rotating bed.
e. Connect sealing caps to electric cables (9 and 10)
and store the cables in the boom butt.
f. Disconnect electric cable from cable reel in butt at
controller on boom butt and at controller on boom
top.
g. Coil cable onto cable reel.
2. Disconnect mast straps from boom (see Figure 4-21
):
a. Lower mast until straps (1b) for insert next to butt
are resting on insert as shown in View B.
b. Unpin links (2, View B) from mast straps (1a) and
store links (2) and straps (1b) as shown in View A.
c. Store pins (5) in pockets on insert (View C).
3. Fully raise mast arms using switch on remote control.
4. Disconnect boom butt:
See Figure 4-20
for the following procedure.
a. Unpin handling pendants (6, View A) from mast and
pin to lugs on boom butt (View D).
b. Boom up until handling pendants (6, View F) are just
taut.
c. Remove pins (12, View G).
DANGER
Falling Mast/Boom Hazard!
Prevent mast from falling:
• Fully raise mast arms before raising mast. Mast will
fall over backwards if raised to vertical when arms are
down.
DANGER
Falling Boom Hazard
Do not remove bottom pins between butt and insert until
handling pendants are connected and supporting boom.
Boom will collapse.
WARNING
Falling Boom Hazard
Do not attempt to lift assembled boom with handling
pendants. Handling pendants could break allowing boom
to fall.
