SET-UP AND INSTALLATION 16000 OPERATOR MANUAL
4-34
Published 05-09-17, Control # 011-29_v2
FIGURE 4-21
Legend
Item Description
1a Mast Strap
1b Insert Strap
2Links
3 Pin (shipping)
4 Link (shipping)
5 Pin, with Collar, Retaining Pin, and Cotter Pins
6 Terminator Plug with Sealing Cap
7 Electric Cable on Crane
8 Electric Cable From Boom
9 Electric Cable from Drum 1 on Boom
10 Electric Cable from Drum 3 on Boom
5
Stored
View C
4
View B
Working Position
1b
4
3
1a
2
5
2
3
1b
View A
Shipping Position
A10740-20a
ARMS DOWN before raising mast with
boom connected to mast straps.
ARMS UP before raising mast with
boom disconnected from mast straps.
Node-6 Front of Rotating Bed
9
M4-3ff
10
View D
6
7 8
P2281
View E
On Right Outboard or
Inboard Side of
Rotating Bed
