Reference Only
Manitowoc Published 05-09-17, Control # 011-29 3-55
16000 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
Remote Control: Wireless and Wired
Displays remote control status by indicating
which switches are closed.
Each control switch corresponds to a number
(see Table 3-5
). Switch numbers are 1 through 8
in row one, 9 through 16 in row two, 17 through 24 in row
three and 25 through 32 in row four. Not all switch numbers
are used. Switch number 14 (Left Front Jack - Extend) is
enabled in example shown.
Table 3-5 Wireless Remote Switch Identification
Tier 4 Engine Diagnostic Information
Engine Prompt
Yellow engine alert symbol is displayed if a
Tier 4 engine fault occurs. Go to the Tier 4
Information Screen to determine the fault.
DPF Icon
Normally grayed out, displays one of three
conditions in color if regeneration inhibit switch
is on (see page 3-19
and Engine Manufacturer’s Manual for
additional information):
ON when DPF is starting to fill. Turn off regeneration
inhibit switch. No immediate action is required.
FLASHING when DPF is nearly full. The operator may
sense a reduction in power. Turn off regeneration inhibit
switch. No immediate action is required.
FLASHING and red engine light ON. The DPF is full.
The operator will notice a significant reduction in engine
power. Turn off regeneration inhibit switch and perform a
stationary regeneration immediately (see Engine
Manufacturer’s Manual for procedure).
DPF Regeneration Inhibited Icon
ON when active regeneration has been
stopped by pressing the regeneration inhibit
switch. Excessive use of regeneration inhibit will result in the
need to service or replace the DPF.
High Exhaust System Temperature
(HEST) Icon
ON when higher than normal exhaust
temperatures exist due to DPF regeneration.
No. Description No. Description
1 Engine Low Speed 16 Right Front Jack - Extend
2 Engine High Speed 17 Left Rear Jack - Retract
7 Boom Pins - In 18 Left Rear Jack - Extend
8 Boom Pins - Out 19 Right Rear Jack - Retract
9 Front Adapter Pins - In 20 Right Rear Jack - Extend
10 Front Adapter Pins - Out 21 All Jacks - Retract
11 Rear Adapter Pins - In 22 All Jacks - Extend
12 Rear Adapter Pins - Out 24 Counterweight Pins - Out
13 Left Front Jack - Retract 25 Mast Lower
14 Left Front Jack - Extend 26 Mast Raise
15 Right Front Jack - Retract 27 Remote Stop
WARNING
High Exhaust Temperatures!
Active DPF Regeneration can occur at low engine idle as
well as during crane operation. This may result in high
exhaust temperature. Always keep personnel well away
from the exhaust to prevent injury and possible death.
