16000 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
See Figure 3-10 for the following indicators.
C6. Fuel Level
Indicates amount of fuel remaining in fuel tank.
C7. Engine Coolant Temperature
See engine manual for operating specifications.
C8. Engine Oil Pressure
See engine manual for operating specifications.
C9. Battery Voltage
Indicates condition of battery charging system.
C10. Drum Rotation Indicators
Pin-type actuators located under all drum handle covers.
They move UP and DOWN to signal the operator, by feel,
that the corresponding drum is turning. Indicator movement
corresponds to drum speed.
C11. Drum Direction Indicators
Glow green to indicate the direction in which a drum is being
operated.
D – Special Controls
See Figure 3-10 for special controls.
D1. RCL Display and Indicator Lights
Displays load lifting information and alerts the operator to
overload conditions. See separate Rated Capacity Indicator/
Limiter Operation manual for detailed instructions.
D2. Main Display
Displays operating conditions, faults, and diagnostic
information. See Main Display topic in this section for
detailed instructions.
D3. Limit Bypass Switch
This switch bypasses the limits identified in Table 3-2 or
Table 3-3
on current production cranes without luffing jib limit
bypass switch (D4).
Insert key. Turn CLOCKWISE and hold to BYPASS
(deactivate) reached operating limits. This position allows
the functions to be operated beyond the limits.
RELEASE to ACTIVATE operating limits. This position
allows the limits to stop the functions in the normal manner.
Remove key to prevent unauthorized operation.
D4. Luffing Jib Limit Bypass Switch
This switch bypasses the limits identified in Table 3-2. This
switch is not provided on current production cranes.
Insert Key. Turn CLOCKWISE to BYPASS corresponding
limits. This position allows functions to be operated beyond
the limits.
Turn COUNTERCLOCKWISE to ACTIVATE corresponding
limits. This position allows limits to stop functions in the
normal manner. Key must be in this position for all
normal operation. Otherwise, structural damage can
occur.
Remove key to prevent unauthorized operation.
D5. Seat Switch
Prevents crane from being operated until operator is seated.
When operator is not seated, all control handles are
inoperable, all brakes are applied, and travel cruise is turned
off.
D6. DPF Switch (Tier 4 Equipped)
NOTE: DPF = Diesel particulate filter (only on cranes with
Tier 4 engine).
The DPF switch is a three position switch. Top position is
momentary. Center and bottom position is maintained.
CENTER position is for NORMAL engine operation.
Regeneration of the DPF will occur automatically.
Press TOP of rocker to START stationary regeneration.
Release switch back to center position. Cummins ECM will
control a DPF regeneration if necessary. It is normal for the
DPF High Temperature lamp to illuminate.
Perform a stationary regeneration only if indicated by the
DPF icon in the Tier 4 Engine Information Screen (see
page 3-55
in this manual for details).
NOTE: A guard over the top of the rocker prevents
unintended regeneration.
Press BOTTOM of rocker to INHIBIT active regeneration.
The amber LED in the rocker will glow.
Use INHIBIT only for special circumstances where it is
desirable to disable active regeneration. Prolonged engine
operation with INHIBIT on will cause the DPF to fill with soot.
Too much soot could cause the engine to stop. If that occurs
it will be necessary to clean the DPF before the engine can
be restarted.
See Engine Manufacturer’s Manual for additional
information.
D7. BRS Jack Switch (Optional)
Refer to the separate Boom Raising System Manual for
detailed operating instructions.
WARNING
When bypassing a limit, carefully follow instructions under
Limit Devices topic in this section.
