OPERATING CONTROLS AND PROCEDURES 16000 OPERATOR MANUAL

3-20

Published 05-09-17, Control # 011-29

Table 3-2 Bypassable Limit Identification

This Table Applies Only to Cranes with Limit Bypass Switch (D3) and Luffing Jib Limit Bypass Switch (D4)

Limit

Limit Bypass Switch (D3)

(momentary key switch)

Luffing Jib Limit Bypass Switch

(D4)

1, 2

(maintained key switch)

Boom Up [55]

Yes or No

Block-Up (each drum) [60] Yes Yes

Minimum Bail — (each drum) [57] Yes No

Luffing Jib Maximum UP 1 [49] Yes Yes

Luffing Jib Maximum UP 2 [73] No No

Luffing Jib Maximum Down 1 [50]

Luffing Jib Maximum Down 2 [67] No No

Mast Too Far Forward [66] Yes Yes

Rated Capacity Indicator/Limiter [54] Yes Yes

MAX-ER

Mast Stop Limit Switch

[27] No No

Use only for rigging.

Luffing Jib Limit Bypass Switch (D4) is not provided on current production cranes.

The boom up limit cannot be bypassed on current production cranes. To determine if the boom up limit can be bypassed

on your crane, perform the test given on page 3-28

in this section.

When you reach luffing jib maximum down limit, operation does not stop. Fault 50 alarm comes on. You can lower luffing

jib an additional 3° to luffing jib maximum down 2 limit.

Numbers in brackets [ ] are fault codes. See Table 3-4 starting on page 3-52.
