Manitowoc Published 05-09-17, Control # 011-29 3-15
16000 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
NOTE: The windshield washer tank is mounted at rear of
cab support. Fill the tank with a quality brand
washing solution that will not freeze during cold
weather.
B4. Climate Control
Provides cab temperature control from 55 to 95°F (13 to
35°C).
A. ON - Depress to turn on climate control system. The
LED will illuminate and display the current temperature
setting.
B. OFF - Depress to turn off climate control system.
C. AUTO - Depress to places system in fully automatic
temperature control mode, to include fan speed. The
system will adjust blower fan speed to the lowest setting
necessary to maintain the selected cab temperature. A
panel indicator light illuminates when this mode is on.
D. DEF (defrost) - Depress to energize the A/C system to
allow for rapid de-humidification of cab. A panel indica-
tor light illuminates when this mode is on.
E. FAN UP/DOWN - Overrides AUTO mode. Depress to
increment fan speed up or down in 11 steps. The LED
indicates the setting as a percent between HI and LO.
The selected fan speed is maintained until changed or
the AUTO mode is turned on.
F. TEMPERATURE UP/DOWN - Depress to raise or lower
the temperature setting. The system maintains the cab
temperature as close as possible to the selected tem-
perature.
G. LED.
H. FAULT CODES - To display fault codes, press ON but-
ton three times. Any active fault codes are shown on the
LED. Displayed fault codes are:
- E00 — No Faults
- E01 — Cab Sensor Shorted
- E02 — Cab Sensor Open
- E03 — Evaporator Probe Shorted
- E04 — Evaporator Probe Open
- E09 — Water Valve Shorted
- E10 — Water Valve Open
To change the display temperature from Fahrenheit to
Celsius or back, depress TEMPERATURE UP/DOWN
buttons simultaneously.
B5. Radio/CD Player (optional)
See manufacturer’s instructions.
B6. Cab Tilt Switch
PRESS and hold TOP of rocker to RAISE front of cab.
CENTER rocker to LOCK cab in position.
PRESS and hold BOTTOM of rocker to LOWER front of cab.
B7. Panel Lights Switch
Press TOP of rocker to TURN ON panel lights.
Press BOTTOM of rocker to TURN OFF panel lights.
B8. Dome Light Switch
Press TOP of rocker to TURN ON dome light.
Press BOTTOM of rocker to TURN OFF dome light.
B9. Horn Switches
Two horn switches are provided: one on the right console
and one on the cab floor. Use either horn when necessary
to warn or signal personnel while the crane is being
operated or serviced.
On right console, PRESS and hold bottom of rocker to turn
ON horn.
RELEASE rocker to turn OFF horn.
On cab floor, PRESS and hold down switch with right foot to
turn horn ON.
RELEASE foot from switch to turn horn OFF.
B10. Cigarette Lighter
B11. 12 Volt Power Supply Receptacle
Provided for operation and charging a 12 volt cell phone or
other appliance.
B12. Machinery Heaters
The hydraulic tank can be equipped with two thermostatically
controlled heaters (120 or 240 volt) designed to keep the oil
temperature 30°F (17°C) warmer than the ambient
temperature.
To aid engine startup in cold weather, plug in the heaters at
shutdown; unplug the heaters at startup.
WARNING
Moving Cab Hazard!
Warn personnel to stand clear of operator’s cab while
tilting.
• Personnel can lose balance and fall.
• Personnel can be crushed between cab and railing.
