Manitowoc Published 05-09-17, Control # 011-29_v2 4-35
16000 OPERATOR MANUAL SET-UP AND INSTALLATION
4
See Figure 4-21 for the remaining steps.
9. Connect electric cable from crane to controller on boom
butt:
a. Remove terminator plug (6, View E) from electric
cable (3) on crane.
b. Connect electric cable (8) from boom butt to cable
(3).
10. Connect electric cables (9, View D) and (10 optional)
from boom butt to node on front of rotating bed.
NOTE: For Node-6 electrical connections with Mast Stop
Limit Switch, reference Figure 4-22
for cranes with
software version M002066 or newer.
11. Lower mast until ends of mast straps (1a) are
approximately 18 in (457 mm) from boom.
12. Connect mast straps (1a, View B) to insert straps (1b),
as follows:
a. Remove pins (3, View A) and rotate links (4) to
working position (View B).
b. Pin links (4, View B) in working position.
c. Remove pins (5, View C) from storage.
d. Rotate links (2, View A) up and pin to mast straps
(1a) with pins (5, View B). Lower mast as required to
align holes.
13. Fully lower mast arms using switch on remote control.
14. Turn off and store setup remote control.
15. Select proper capacity chart on configuration screen of
RCL display.
16. Boom can now be raised. Perform Pre-Raising
Checks.
DANGER
Falling Mast/Boom Hazard!
Prevent mast and boom from falling:
• Fully lower mast arms before raising boom. Mast can
buckle and collapse if it contacts mast arms with a
fully rigged boom.
