OPERATING CONTROLS AND PROCEDURES 16000 OPERATOR MANUAL
3-12
Published 05-09-17, Control # 011-29
FIGURE 3-5
Right Side of Upperworks
A2
Low Idle
High Idle
A4
A3
A1
A02019
P2290
A09260
A1297
Pull Out to
Engaged
Disengaged
Position
A5
A6
Hydraulic Heater
Electrical Cord
(1 each side of crane)
Shown in
Connected (Closed)
Position
To Disconnect
