Manitowoc Grove RT9150E User Manual

1-7
RT9150E OPERATOR MANUAL INTRODUCTION
1
Published 2-23-2017, Control # 644-00
Grove
Table 1-1: Axle Weight Distribution Table
Description
CG Weight Front Axle Rear Axle
in cm lb kg lb
kg
lb
kg
Maximum Tire Loads Allowed at 15 mph
(With no Counterweight Installed)
- - 90000 40823 90000 40823
Maximum Tire Loads Allowed at 10 mph
(With Standard Counterweight Installed)
- - 98832 44829 98832 44829
Maximum Tire Loads Allowed at 2.5 mph
(With Heavy Counterweight Installed)
- - 130640 59257 130640 59257
Carrier 4x4 with all Fluids 83.13 211.15 52293 23720 22350 10138 29943 13582
Front outrigger box and beam assembly
266.00 675.64 9427 4276 12892 5848 -3465 -1572
Rear outrigger box and beam assembly -82.00 -208.28 9427 4276 -3974 -1803 13401 6079
Superstructure with cable on both hoists 21.10 53.59 16177 7338 1755 796 14422 6542
Superstructure with cable on main hoist only 26.50 67.31 15300 6940 2085 946 13215 5994
Install Standard Counterweight -52.17 -132.51 39000 17690 -10461 -4745 49461 22435
Install Heavy Counterweight -52.17 -132.51 63000 28576 -16898 -7665 79898 36241
Main Boom 239.87 609.27 33438 15167 41238 18705 -7800 -3538
Lift Cylinder at 0º 201.91 512.85 2883 1308 2993 1358 -110 -50
Complete basic machine, including all of the
above with the standard counterweight and
cable on main hoist only.
80.70 204.98 161767 73376 67119 30445 94648 42932
Add to Basic Unit
36/59 ft (11-18 m) Bi-fold Boom Extension
(includes brackets on boom)
286.92 728.78 3477 1577 5129 2327 -1652 -749
36/59 ft (11-18 m) Bi-fold Hydraulic Boom
Extension (includes brackets and hydraulic
components on boom)
305.46 775.87 4023 1825 6318 2866 -2295 -1041
36/59 ft (11-18 m) Bi-fold Heavy Hydraulic
Boom Ext. (includes brackets and hydraulic
components on boom)
312.63 794.08 4547 2062 7309 3315 -2762 -1253
Brackets and hydraulic components on boom
for hydraulic boom extension
358.30 910.08 666 302 1227 557 -561 -254
Brackets for manual boom extension 247.31 628.17 251 114 319 145 -68 -31
10 ton (9.0 t) Headache Ball (Swivel)
attached to outrigger box
310.00 787.40 727 330 1159 526 -432 -196
100 Ton Domestic Hookblock - Stowed in
trough
185.00 469.90 2535 1150 2411 1094 124 56
130 Ton Domestic Hookblock - Stowed in
trough
185.00 469.90 2530 1148 2406 1092 124 56
90 Metric Tonne CE Hookblock - Stowed in
trough
185.00 469.90 2555 1159 2430 1102 125 57
120 Metric Tonne CE Hookblock - Stowed in
trough
185.00 469.90 2544 1154 2420 1098 124 56
Auxiliary Boom Nose Installed 513.75 1304.93 133 60 351 159 -218 -99
Reference Only
