Appendix 3 – Technical Specifications
106
F6 SMART™ – Volumetric Handheld Camera – User Guide
Appendix 3 Technical Specifications
Specifications of all components of the F6 SMART™ System are detailed below:
F6 SMART™ Camera Hardware Specifications
Item
Data
Camera Sensor
CMOS (Sensor Aptina AR0134 1.2M)
Accuracy
0.1% – 0.2% upon scanning distance.
XY point density
5mrad
Low noise level (Single
Frame Accuracy)
Up to 0.5 mm at a range of ≤ 1 m
Projector Wavelength
845 nm – 856 nm (Infrared)
Projector Light Source
ARRAY Laser (Class 3R Laser)
Product Eye Safety Rating
Class 1 Laser Product
Ambient lighting
Complete darkness up to direct sunlight (~25Klux). Range
degrades in the presence of IR light sources.
Depth of field (scanning
range)
60 cm – 4 m (24" – 157")
Linear field of view
H x W = 510 x 670 mm, closest range.
H x W = 4,585 x 6,070 mm, furthest range.
Angular field of view
V x H x D = 53° x 68° x 80°
Color (RGB) Camera
Resolution
1.3 Megapixel
NIR Sensor Resolution
1.2 Megapixels
Video frame rate
8 fps
Exposure time
0.005 – 0.04 seconds
Data acquisition speed
640,000 points/seconds
Continuous Acquisition
Minimum Data Storage Capacity: 1 hour (normally ~2
hours).
Minimum Battery Life
2 hours
Power consumption
Internal battery and/or USB source
Scanning time
Up to 3 hours
