Mantis Vision F6 SMART Echo - Echo Software Specifications

Saving & Exporting
F6 SMART™ – Volumetric Handheld Camera – User Guide
107
Dimensions (Outer
Boundary)
H x D x W = 32cm x 12cm x 4.5 cm (12/5" x 4.7" x 1/7")
Weight
1.4kg (~3.0lb)
Calibration
No special equipment required.
Ambient Operating
Temperature Range
-10°C to 50°C (14°F to 122°F)
Table 1 – F6 SMART™ Camera Hardware Specifications
Power Management in the F6 SMART™ Camera
WARNING:
Internal battery may be replaced at a manufactory
certified laboratory only.
Echo™ Software Specifications
Item
Data
Minimum free hard disk space
for installation
90 Mb (without the Visual Studio™ and the FTDI
Driver).
Recommended working disk
space
Output formats
PTS, ASCII, PLY, E57, STL
Operating System (OS)
Supported
Microsoft™ Windows™ 7 Pro (64bit) or higher.
Windows™ 10 Pro (64bit) recommended.
Table 2 – Echo™ Software Specifications
Workstation Specifications
