● The 12-pin Bayonet-Lock Miniature connector – to the F6 SMART™ Camera (below
the Hand Grip).
Powering the F6 SMART™ Camera
Turn the F6 SMART™ Camera’s power ON by briefly holding down the Power/Scan Button
(inner side of the F6 SMART™ Camera’s Hand Grip) for 3-4 seconds until:
● The red LED indicator (at the outer top end of the Hand Grip) turns on, and,
● The workstation sounds a typical notification beep sound.
As per USB standard, the workstation will automatically identify the newly connected F6
SMART™ Camera and embed it into the workstation’s supported devices’ list.
NOTE:
The red LED will only turn on following a USB protocol
handshake between the F6 SMART™ Camera and the
workstation.
The F6 SMART™ Camera will not power on with no proper
connection between the F6 SMART™ Camera and the
workstation.
Verification of Connection
One other type of verification to the connection between the F6 SMART™ Camera and
the workstation (on top of the above-mentioned LED) utilizes Window’s Device Manager
mechanism, as follows (see Figure 24 – Verification of F6 SMART™ Camera Connection
below).
1. Activate Windows’ Control Panel and select Device Manager from the menu.
The Device Manager Window opens (see Figure 24 below.)
2. Expand the Universal Serial Bus Controllers Directory and check to see that “ USB
Serial Converter A ” and “ USB Serial Converter B ” items (highlighted in Figure 24
below) were added.
