F6 SMART™ – Volumetric Handheld Camera – User Guide
83
Distance
To measure the distance between two points, click on the Distance button, which will
then appear highlighted in blue next to the scan. Double-click on the first point location,
then double-click on the second point location. The distance between the two points
appears in the Measurement History.
Angle
To measure an angle, click on the Angle button, which will then be highlighted in blue
next to the scan. Double click on the first location, then double-click on the second
location; green X’s appear at each of the two points. The angle between the two points
appears in the Measurement History.
Point to Plane
To measure the distance between a point and a plane, click on the Point to Plane button,
which will then be highlighted in blue next to the scan. Double click on the first location,
then double-click on the second location and again on the third location. The angular
point vertex will be shown. When you double-click a fourth time, the distance from the
point to the plane appears in the Measurement History.
Point to Line
To measure the distance between a point and a line, click on the Point to Line button,
which will then be highlighted in blue next to the scan. Double click on the first location,
then double-click on the second location to create the line. When you double-click a third
time to mark the point, the distance from the point to the line appears in the
Measurement History.
