Installation of Echo™ Software
F6 SMART™ – Volumetric Handheld Camera – User Guide
Chapter 5 Installation of Echo™ Software
The method of installing the Echo™ software resembles most other Windows™-based
applications’ installation processes and described thoroughly hereinafter.
NOTE:
During the process of installing the Echo™ software, the F6
SMART™ Camera
be connected to the
workstation!
Downloading the Latest Echo™ Software Version
The Echo™ software is encapsulated in the USB Flash Drive (Disk-on-Key) device included
in the F6 SMART™ Kit case (see Figure 4 on page 22 above).
It is suggested to check Mantis Vision’s website for availability of a more progressive
version.
If a more progressive version is available – download it onto the workstation for
installation instead of the USB-drive included version.
Content of the USB Disk-on-Key Flash Drive
The USB flash drive contains:
● The installation program –
setup.exe
.
●
Prerequisites
sub-directory containing a few directories and files associated with the
installation process.
●
Scanner Explicit Calibration Files
:
coloring.txt
– a file containing calibration data for the Color (RGB) Camera.
config.ecfg
– a file containing general F6 SMART™ configuration data.
rig.txt
– a file containing calibration data between the NIR Sensor and the Color
(RGB) Camera.
