Masimo Root User Manual

Root NIBPT Chapter 3: Operation
www.masimo.com 56 Masimo
Trends for Temperature
From the Temperature screen, touch Trends, and then change any of the following options:
Options Description
Factory Default
Settings
Configurable
Options
Y-Axis Max
(°F)
The Temperature Trend Max.
The upper limit a measurement
will be shown.
110.0
80.1-110.0 in steps
of 0.1
Y-Axis Min
(°F)
The Temperature Trend Min.
The lower limit a measurement
will be shown.
80.0
80.0-109.9 in steps
of 0.1
Y-Axis Max
(°C)
The Temperature Trend Max.
The upper limit a measurement
will be shown.
43.3
26.8-43.3 in steps of
0.1
Y-Axis Min
(°C)
The Temperature Trend Min.
The lower limit a measurement
will be shown.
26.7
26.7-43.2 in steps of
0.1

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
