Root NIBPT Chapter 3: Operation
www.masimo.com 69 Masimo
Radical-7 and Radius-7 Battery
Use the Battery screen to view the specific percentage of charge on the Radical-7 or
Radius-7's battery. For Radical-7, the user can also access the Battery screen by pressing the
Battery icon on the Status Bar. See About the Status Bar on page 34.
Option Description
State of Charge Provides a read-only display of battery level remaining.
Battery Diagnostics
Allows trained personnel to access battery diagnostic information.
Brightness
Use the Brightness screen to adjust the brightness of the Root display.
Option Description Factory
Default
Setting
Configurable
Settings
Auto
Brightness
Allows automatic adjustment of Root's
display brightness based on ambient light.
Off On or Off
Brightness
Adjust the brightness level of the Root
display by sliding the button (4 is
brightest).
4 1, 2, 3, 4
