Masimo Root User Manual

Root NIBPT Chapter 3: Operation
www.masimo.com 75 Masimo
Trend Settings
Use the Trend Settings screen to configure trend viewing on the Main Screen and trend data
storage on Root.
Option Description Factory Default
Setting
Configurable Settings
Default
Duration
Duration captured by
Trend Graph.
2 hours
15, 30, and 45 minutes
1, 2, 4, 8, 12, 24, 48, 72, and 96
hours
Clear Trends
Delete all stored trend
data.
N/A
Press Clear to delete all stored
trend data.
To configure trend settings for specific parameters and measurements, see Directions for Use
or Operator's Manuals for Radical-7, Radius-7, and appropriate MOC-9 module(s).
Profiles
Use the Profiles screen to select patient type.
Option Description Factory Default
Setting
Configurable Settings
Profile Name
Identifies the Profiles setting
in the device.
Adult
Adult, Pediatric,
Neonatal, Custom
Configure
Profile
Identifies the patient category
type.
Adult Adult, Pediatric, Neonatal
Root can be configured for various patient types by using the Profiles feature. Profile selection
controls the management of patient configuration settings on Root. The settings of the three
default profiles (Adult, Pediatric, and Neonatal) configure parameter alarms, averaging time,
and sensitivity modes.

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
