TROUBLESHOOTING 10 - 1
D-MAXE with OI-B/OI-Nwww.maxcessintl.com MI 2-296 1 D
Fehlersuche.fm
10 TROUBLESHOOTING
Troubleshooting
procedure
The D-MAXE system is capable of detecting errors as they occur
and displaying them. The system also makes information
available that may help exclude possible errors.
Display possibilities The following display possibilities are available on modules of
the D-MAXE system:
– LEDs on the front sides of the D-MAXE Controller
– LEDs* L1 and L2 on the front of the D-MAX operator interface
– LEDs* on connections X2 ... X6 of the D-MAX operator
interface
– Icons in the display of the D-MAX operator interface
Note:
The LEDs marked with * are not available on the virtual D-MAX
operator interface.
Procedure 1. Check the LEDs on the individual modules of the D-MAXE
systems
 see table
10-2
2. Check the icons that appear in the display of the D-MAXE
operator interface
 see page
4-4
3. Check possible causes for faulty behavior. Frequent causes
are connections or settings on the D-MAXE system
 see table
10-9
4. Check the faulty behavior and possible causes. Often the
cause is incorrect parameter settings
 see table
10-12
Note:
The Operating Instructions of other components (e.g. sensors
and actuators) should also be consulted for troubleshooting
purposes. If there is any customer-specific programming, refer
to the "Supplementary Operating Instructions" also.
