OPERATOR INTERFACE MENUS5 - 4
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
Menu 1.a.2.1 BMP
Orientation
Description The BMP Orientation menu is used to set the alignment of the
graphic shown in the display (bitmap). This makes it possible to
coordinate the installation position of the actuator in the
customer system and the position of the operator interface.
Menu
 Key sequence for menu 1.a.2.1:
The current setting for the BMP Orientation parameter is shown
here.
 Select the "device" in the list for which the BMP Orientation
parameter will be set
 Enable the parameter for input
Input
Menu
1.a.2.1.1.1: BMP Orientation
 Select the desired entry in the list
 Save the entry or cancel
1.a.2
→ Control Options
or
→ Press longer than 2seconds
1.a
1.a.2.1
→ BMP Orientation
or
or
or
or
