CONTROLLER MENUS: 1Y.5 HARDWARE IOS7 - 30
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
Menus 1y.5.1.7 Encoder
(X3)
These menus are used to calibrate the encoder on input X3.
Menus 1y.5.1.8 Motor
Encoder (X4)
These menus are used to calibrate the motor encoder on input
X4.
Menus 1y.5.1.7 Encoder
(X7)
These menus are used to calibrate the encoder on input X7.
Menus 1y.5.1.8 Motor
Encoder (X10)
These menus are used to calibrate the motor encoder on input
X10.
General information about
these menus An incremental position transducer (encoder) can be connected
to each drive on the D-MAXE to record positions. This makes
position monitoring and evaluation possible.
In most applications, the encoder is used together with a sensor
positioning system.
Note:
Generally the encoder is already preset when it ships from the
factory. Therefore a resetting is required only when replacement
parts are installed.
Note:
The menus for the motor encoder are not present unless a
corresponding motor is present on the selected drive.
