7 CONTROLLER MENUS
Notes This section is a description of menus that are needed for
commissioning and to make other settings in the D-MAXE
system.
Section
Menu structure D-MAXE Controller, page 12-1
contains
an overview of all menus.
Conventions The following conventions apply to the menus described here:
– Select "device":
Make certain the correct D-MAXE processor and drive are
selected on the Controller ("Device").
– To reach the user level:
The key sequence for a given menu is always based on the
assumption that the D-MAXE system is in the user level. To
do this, continue pressing the "ESC" key or hold it down until
you reach the user level.
– To set "Manual" mode:
All menus in the D-MAXE system are described in "Manual"
mode (x = 1), since that is the only mode in which all menus
can be reached.
–To select a job:
Make certain the correct job is selected.
– x
Placeholder "x" is the operating mode currently set in the
"device" (see
Menu identification, page 5-9
).
(in the example x = 1)
– y
Placeholder "y" is the job currently set in the "device" (see
Menu identification, page 5-9
).
(in the example y =
A)
This place in the menu identification changes depending on
the job selected by the customer.
