OPERATION4 - 15
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
Manual mode
Description There is no guiding of the web course. The settings of the
D-MAX system can be changed.
Menu ∙ F3 key for "Manual“ menu (
1y)
The bar graph identifies the position of the guidepoint of the
sensor selected with F4.
Operator control options The following operating option are available in "Manual" mode.
Key Description
Switching between existing "devices" is
possible
Switch to "Automatic“ mode
Switch to "Servo-Center" mode
The drive can be moved
The job can be selected
Switch to menu level
All menus are available.
