Maxcess D-MAXE - Shift Guidepoint

OPERATION4 - 17
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
Shift guidepoint
Description The guidepoint can be shifted in "Automatic" mode during
ongoing operation.
Note:
This is only possible if the parameter has been set up
appropriately in
Menu 1y.6.2 Job Enable, page 7-43 .
Menu Move the guidepoint to the desired position with the arrow keys
A triangle and guidepoint shift percentage appear under the bar
graph at the point to which the guidepoint was moved.
Reset the guidepoint
∙ Press the arrow keys together to reset the guidepoint
The guidepoint is reset to 0%. The triangle under the bar graph
disappears.
Note:
This parameter can also be set with menu 3y.3.y1 guidepoint
offset or with
Menu 1y.3.y1 Guidepoint Offset, page 7-5 .
or
and
