TECHNICAL DATA11 - 3
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
Inputs and outputs of
the D-MAXE Controller
Communication interface
based on Ethernet - 100 Mbps full duplex
[Note 3]
Electromechanical drive
maximum 4A/drive
Hydraulic servo-valve
±50mA
with or without lock valve (24V or 48V, maximum 4A)
Motor Power Amplifier MPA
±10mA
with MPA locking signal
Servo-Center transducer
Analog, inductive Servo-Center transducer
Sensor input
Maximum
±20mA
Preset range 0 to 10mA
Sensor inputs can be calibrated individually
Line speed
0 to10mA
Calibration optionally possible between 0 to 20mA
Power supply for accessory devices
[Note 3]
+12V ± 5%, 2000mA total
-12V
± 5%, 150mA total
+24V
±5%, 1000mA each sensor connection and serial
connection
