LEDs on the D-MAXE
Controller
While the device is being turned on, the LEDs on the D-MAXE
Controller are lit red briefly. This makes it possible to check
their functionality. The LEDs indicate errors and/or show
information about normal operation of the D-MAXE Controller.
LED Status Indicates Remedy
Error messages
E1
(X2/1)
Off No Ethernet connection Check plug and cable
Yellow 10mbps connection or half-
duplex connection
Check switch and cable
E2
(X2/2)
Off No Ethernet connection Check plug and cable
Yellow 10mbps connection or half-
duplex connection
Check switch and cable
PR Off No power supply Are the power supplies correctly
connected to the X6?
See
Electrical connection, page 3-6
Is a fuse blown?
See
Fuse replacement, page 10-14
Red Power supply voltage too low,
internal voltage outside
tolerance or internal
temperature too high
Check voltages and/or temperature
See
Menu 1y.9.1.7 Power , page 7-
57
Yellow No motor voltage Check motor voltages
See item 2 in
Menu 1y.9.1.7 Power ,
page 7-57
Is a fuse blown?
See
Fuse replacement, page 10-14
Information
E1
E2
Green or
Green
flashing
Ethernet connection detected
NW Green External device was
recognized (e.g an operator
interface OI-TS)
PR Green Power supply and temperature
are OK
