INSTALLATION 3 - 11
D-MAXE with OI-B/OI-Nwww.maxcessintl.com MI 2-296 1 D
Montage.fm
x Connection present
- Connection not present
* CompactCom interface (fieldbus) for communication
with PLCs
(Information about the interface may be found in
"Supplementary Operating Instructions" in the system
documentation.)
For technical details and additional information, please consult
Section
11 Technical Data
.
MAXNET addresses ∙ MAXNET is a proprietary protocol used for communication
between D-MAXE Controllers and D-MAXE operator
interfaces.
∙ The MAXNET address of the D-MAXE Controller must be
different than the addresses of other controllers on the
network (addresses 1 to 31).
∙ The MAXNET address of the operator interface is permanently
set in the factory and cannot be changed. Generally it is set
to 0, except when the operator interface is used as a Gateway
(X7).
Connection
OI-B OI-N Description
X1 x x Power supply voltage
X2 x x Ethernet Port
X3 - x Ethernet Port
X4 - x Ethernet Port
X5 - x Ethernet Port
X6 - x Ethernet Port
X7 -
Optional
CompactCom interface *
