Selection of "devices"
The A key is used to select individual "devices" present on the
network, for example the D-MAXE Controllers and their drives
as well as any customer-specific system menus (CM) or
Gateways that may be present.
Fig 4.5 describes how controllers and drives are identified in the
status line.
To select a specific "device", press the
 A key until the desired menu appears,
or
 hold the A key for longer than 2seconds.
A list appears with all the "devices" present in the network
from which the "device" may be selected.
Shows the currently selected
Shows the currently selected
Figure 4.5: Identification in the status line
1/ 2
"device" on the processor
Processor on
