OPERATION 4 - 14
D-MAXE with OI-B/OI-Nwww.maxcessintl.com MI 2-296 1 D
Bedienung.fm
Servo-Center operating
mode
Description The actuator is moved to the mechanical center position
depending on the Servo-Center transducer. Then the control
rollers are aligned parallel to the rollers of the customer system.
Menu ∙ F2 key for "Servo-Center“ menu (
2y)
The bar graph identifies the position of the Servo-Center
transducer's guidepoint.
Operator control options The following control options are available in "Servo-Center“
mode.
Key Description
Switching between existing "devices" is
possible
Switch to "Automatic“ mode
Switch to "Manual" mode
Selection of job for "Automatic" mode
possible
Switch to menu level
Only restricted menus are available.
